Laser / Detector Modules
Bidirectional optical communication with laser and detector in one housing.
Lasers/Detector Modules
PD-LD’s PW series transceivers combine an optical transmitter and an optical receiver both in the same housing. They are available in 850 nm, 1310 nm, and 1550 nm wavelengths. It is possible to either send and receive with the same wavelength or to send with one wavelength and detect with another.
LEDs are used as transmitters, and InGaAs PIN photodiodes as low-noise receivers. With an operating temperature of -40°C to +85°C, these modules are suited for all industrial applications, such as video data transmission or bidirectional WDM systems with a single fiber.
- PW15M11 Series SM 1550 TX / 1310 RX Bidirectional 125 GB/s PINTIA RX (PDF, 299.1 KB)
- PTRX155ST-2 MM &SM 1x9 Dual ST Transceiver 155MBs 5V (PDF, 385.4 KB)
- PSFB-B35 Bi-directional SFP Transceiver (PDF, 316.2 KB)
- PSFB 1.2 1.25 Gbps Single Mode SFP Transceiver (PDF, 392.2 KB)
- PTR155-B35/B53 155 Mbps Bi-directional Single Mode 1x9 Transceiver (PDF, 208.8 KB)
- PTR155-B35/B53-M 155 Mbps Bi-directional Multi Mode 1x9 Transceiver (PDF, 208.4 KB)
- PTR622-B35/B53 622 Mbps Bi-directional 1x9 Transceiver (PDF, 354.3 KB)
- PTR622-B35/B53-PT Pressure-Tolerant Transceiver (PDF, 291.3 KB)
