Portable Wavefront Metrology System

Optical Engineer’s Companion (OEC) for fast, precise optical system alignment.

Portable Precision for Optical Testing Anywhere

The Optical Engineer’s Companion (OEC) from Imagine Optic is a portable, high-performance wavefront metrology system designed to support optical engineers in both laboratory and field environments. Compact and rugged, the OEC enables quick, reliable analysis and alignment of complex optical systems, making it an essential tool for research, prototyping, and system maintenance. Its intuitive software and plug-and-play design ensure ease of use without compromising precision, making wavefront diagnostics accessible to both experts and non-specialists.



Advanced Shack-Hartmann Sensor for Fast, Accurate Alignment
At the heart of the OEC is a high-resolution Shack-Hartmann wavefront sensor offering λ/100 RMS repeatability and high dynamic range. It supports a wide range of wavelengths and configurations, with built-in analysis functions such as Zernike decomposition, MTF, PSF, and Strehl ratio calculations, it supports real-time measurement and alignment tasks. Whether used in R\&D, industrial inspection, or on-site testing, the OEC delivers precise, actionable metrology in a truly portable format.

Markets & Applications

  • Optical R&D Laboratories
  • Aerospace and Defense
  • Industrial Optics and Manufacturing
  • Medical and Biomedical Optics
  • Astronomy and Telescope Maintenance
  • Laser System Integration

Benefits

  • Portability and Field Readiness – ideal for on-site diagnostics and alignment without sacrificing precision.
  • Fast and Accurate Wavefront Analysis - real-time, high-resolution measurements for confident optical system assessment.
  • Versatile Applications Across Environments - supports multiple wavelengths and optical configurations.

Features

  • Wavefront Accuracy:  λ/100 RMS repeatability (at 633 nm)
  • Aperture Size: Up to 11 mm clear aperture
  • Measurement Speed: Up to 10 Hz real-time acquisition rate
  • Dynamic Range: From -π to +π radians, enabling measurement of highly aberrated wavefronts
  • Sensor Type: High-resolution Shack-Hartmann wavefront sensor
  • Wavelength Range: From 400 to 1100 nm, depending on model configuration
  • Spatial Resolution: Up to 77×77 microlens array (measured in sub-apertures)
  • Data Interface: USB 3.0 connection for fast data transfer
  • Form Factor: Compact dimensions: ~150 × 100 × 60 mm, weight <1 kg
