Multi-channel LiTaO3 Pyroelectric Detectors

Multi-Color Detectors

Multi-channel pyroelectric detectors (multi-color detectors) are mostly used for gas analysis. Aside from a reference filter, each measurement channel is tuned to a gas absorption line by integrating a bandpass filter. The gas concentration is calculated by applying the Beer-Lambert law. A reference channel improves the long-term stability of the measurement.

Laser Components offers a wide variety of standard bandpass filters for gas analysis (e.g., CO₂, CO, NO₂, SO₂, and hydrocarbons) and reference purposes.
In our datasheet on filters you will find the corresponding filters. Additional filters are available upon request.

Current Mode Pyrodetectors - CM Mode

The same fundamental principles apply to both multi-channel and one-channel detectors in current mode. The detectors in current mode are particularly easy to integrate into systems; in fact, it is almost identical to Plug&Play integration.

The most compact detector is the three-channel version in a TO-39 housing!

The following product lines are available:

Two-channel detectors with filters
L12 and L22 series
Three-channel detectors with filters
L13 and L23 series
Four-channel detectors with filters
L14 and L24 series

Fields of Application

Pyroelectric detectors can be used for:

Medical gas analysis such as breath gas analysis
Industrial gas analysis
Flame detection
Hydrogen flame detection
