Pipe Inspection with Ring Laser Module
Laser Components Developed New Radial Laser Module for Tube Production
Author: Stefan Krauß and Matthias Kramer
Published: inspect 07/2022, Wiley VCH GmbH
The perfect roundness of pipes and pipelines must meet very strict industry standards due to high safety requirements. The new pipe inspection system GMS-I from MSG Maschinenbau measures the internal contour of the pipe using a freely suspended measuring lance equipped with a newly developed ring laser module, the FLEXPOINT® radial. This machine vision innovation enables corrections during the manufacturing process for the first time and significantly speeds up the measurement procedure.
Read more about it in the article by Stefan Krauß and Matthias Kramer:
- Problems with current measurement methods in end-of-line quality control of pipes
- Basic principle of the new in-line inspection system
- Requirements for the ring laser module and machine vision camera
- Innovative application possibilities in manufacturing and quality control
Download PDF (German version only)
Click here
Product Overview
Beyond Borders
Blue/violet, green and IR solid state lasers
The small LC-LMD-650-12 laser modules are coaxially aligned models that are available as part of our LMD low-cost laser module series.
10 W in the blue spectral range at 445 nm
New NIR laser diodes from 785 nm to 1550 nm
The classic among laser diodes, they are available in a large variety and usually ex stock.
Blue laser diodes at 405 nm with 20 mW and at 450 nm with up to 1.6 W.
Green laser diodes (510 nm to 530 nm) are most visible to the human eye.
Fiber-coupled CWDM laser diodes from 1470 nm - 1610 nm
DFBs are semiconductor-based lasers that integrate a grating structure inside the gain chip to stabilise the laser at a fundamental level.
